Product Overview
SAIKE 852D+ is a 2 in 1 hot air rework and soldering station designed for phone repair, PCB maintenance, SMD soldering and training benches.
Model Position
Use this model for repair benches that need a stable hot air gun and soldering iron in one machine.
Key Features
- PID temperature control tracks the working temperature quickly and supports fast temperature compensation.
- The machine includes self-diagnosis and display/protection for over-temperature, short circuit, open circuit and overload faults.
- A rear fuse holder and grounded metal parts help improve electrical safety.
- The hot air gun heater uses the skeleton type ceramic heating core, and the the design supports stable operation and longer heater service life.
- The handle of the hot air gun is equipped with an induction device, as long as the handle is picked up from the handle frame, the hot air gun can quickly enter the working state; Put the handle back on the handle frame, the hot air gun will stop heating, delay blowing cold air to cool down, and finally enter the standby state; Convenient real-time operation, while extending the service life of the heater.
- hot air gun uses a brushless fan as the air source, air volume is large, air volume is adjustable, gentle wind power and minimal noise.
- Soldering iron uses 132A ceramic heating core, stable heating, rapid warming, reduce loss, long service life.
- The soldering iron is designed with anti-static protection, to prevent electrostatic damage to sensitive SMD components.
Component Function Notes
hot air gun
By generating a hot air flow, the solder is heated to a molten state, thus achieving welding, heat shrinkage, removal and other operations.
- Suitable for various kinds of soldering or desoldering work of the electronic components, such as: SOIC, CHIP, QFP, PLCC, BGA, SMD, etc. (especially suitable for mobile phone wiring and wiring base sealing-off).
- Can also be used for heat shrinkage, drying, paint removal, adhesion removal, thawing, preheating, glue welding, etc.
Soldering Iron
The soldering iron transfers heat through the tip to melt solder for soldering and desoldering work.
- Suitable for small solder joints or pads, such as thinner, smaller welding materials, no surrounding metal and other heat-absorbing parts.
- For relatively thick and large solder joints and pads, you can try replacing the soldering iron tip with a larger contact area or use a hot air gun for welding.
Technical Specifications
| Model | 852D+ |
| Input voltage | 220V~240V/AC, 50Hz (110V/AC, 60Hz) |
| Power consumption | 740W |
| Weight | 3.45kg |
| Inner box size | 330*274*204mm |
| Packing quantity | 6 pieces / box |
| Outer packing size | 570*350*625mm |
| hot air gun | |
|---|---|
| Working voltage | 220V~240V/AC, 50Hz (110V/AC, 60Hz) |
| Power consumption | 700W |
| Display form | LED digital (Resolution 1℃) |
| Heating element | Skeleton type ceramic heating core |
| Temperature range | 100℃－500℃ |
| Temperature stability | ±1℃ |
| Type of air flow | brushless fan airflow |
| Gas flow | 120 L/min(max) |
| Noise | Less than 45dB |
| Handle length | About 100cm(Including handle line) |
| Soldering iron | |
| Working voltage | 24V/AC |
| Power consumption | 40W |
| Display form | LED digital (Resolution 1℃) |
| Temperature range | 200℃－500℃ |
| Heating element | 132A ceramic heating core |
| Temperature stability | ±2℃(no load) |
| Handle length | About 100cm(Including handle line) |
Standard Configuration
- Host machine (include hot air gun handle): 1 pcs
- hot air gun rack: 1 pcs
- Soldering iron handle (include iron tip and heater): 1 pcs
- Soldering iron holder (include Cleaning sponge): 1 pcs
- Nozzles: 4 pcs (5mm, 8mm, 10mm, 12*12mm)
- User manual: 1 pcs
Typical Applications
- Electronic product assembly
- Product development in scientific research departments
- Electronic products maintenance
- Electrical soldering operation
- electronics training and repair education
Order and Configuration Notes
Please confirm rated voltage, power plug, order quantity and accessory requirements before production or shipment. For distributor orders, repair shop bundles or accessory kits, contact SAIKE with the target models and quantity so we can confirm a suitable configuration.
